The EV Charging Tester
for Engineers and Innovators

1. Advanced Charging Testing Capabilities

• Comprehensive testing of AC and DC charging interfaces, supported international standards:
  • AC, DC-CCS Type 1 + 2 & NACS: IEC 61851-1, DIN 70121, ISO 15118 incl. ISO 15118-20, SAE J1772, CharIN Test Cases, ISO/IEC 61851-24 and ISO/IEC 61851-23
  • CHAdeMO: 0.9.1, 1.0, 1.0.1, 1.1, 1.2 and 2.0.
  • GB/T DC (China): GB/T 27930-2011; GB/T 27930-2015 and GB/T 18487.1-2015.
  • MCS (Megawatt charging): coming soon, when standards get finished.
• High-Power Testing: Supports with EVCA Flex up to 1500 V, 500 A and optional up to 1000 A for megawatt charging (MCS), ensuring readiness for next-generation charging interfaces.
• Short-Circuit Testing During Charging: Perform high-power short-circuit EVSE tests (IEC 61851-23 compliant) up to 1000 V and 500 A, a capability unique to comemso.

2. Flexible and Scalable Design

• Modular architecture supports R&D, certification, field applications and production lines.
• Cost-effective entry systems with the ability to scale up by reusing parts for hardware upgrades.
• Support of different DC loads or a bidirectional power supply for EV lithium battery emulation.
• Options for field applications with the portable EVCA Multi-Mobile Flex and high-power testing with EVCA Flex. Combine both for measurements in the field and automated protocol-level focused emulation for both EV and EVSE communication in the lab, allowing detailed testing of real-world message content and timing.

3. User-Friendly Software, Unique Features, Interfaces

• Com.frame Testing and Simulation Software: Simplified, intuitive UI for configuring and managing tests.
• Full Charge Playback: Replay recorded test data to emulate specific EV and different chargers communication scenarios.
• Professional Sim: Configure communication parameters, content, and timing for advanced holistic protocol testing.
• Manual control: complete transparency with graphical circuit representations. Manage all electrical parameters directly.
• Manipulating Gateway: Resolve interoperability issues in real time with dynamic adjustments.
• Monitoring Panel: Visualize compliance with color-coded feedback (red for non-compliance, blue for compliance).
• Charge cycle automation: Easily automate the execution of multiple charge configurations.
• REST API: interact with your other test automation software for R&D and production line

4. Comprehensive Testing Libraries: Protocol and Electrical Testing

• Extensive conformance test libraries for global standards like IEC 61851-1, IEC 61851-23, DIN 70121, ISO 15118, SAE J1772, CharIN CCTS, CHAdeMO and GB/T.
• Protocol and electrical conformance libraries for charging stations, power electronics and EV test.
• Customizable test cases, enabling engineers to create half-automated tests or modify parameters of test libraries and save them as reusable templates (depends on the testing standard).

5. Serviceability and Reliability

• Modular service design: Replace individual electronics modules without returning the entire system for repair and upgrades.

6. Specialized Testing Applications

• Power Factor Analysis: Ensure EVSE systems meet grid and energy efficiency standards.
